Polyurethane Silicone Conveyor Belt for Electronic Semiconductor Industry
Polyurethane Silicone Conveyor Belt Suitable for all electronic semiconductor industry product transportation and anti-static requirements of the process.
- Introduction
Introduction
Product features: a cloth and two rubber full-body anti-static, surface technology can be done glossy, matte, fabric pattern.
Suitable for: all electronic semiconductor industry product transportation and anti-static requirements of the process.
 |
Model | JU02 |
| Material | Polyurethane | |
| Tensile material | Polyester | |
| Color | Black | |
| Surface | Glossy/Matte/Patterned | |
| Antistatic | Possible | |
| Hardness | 50-90 Shore A | |
| Temperature Resistance Range | -20+80* | |
| Minimum Wheel Diameter | 15mm | |
| 1% Constant Elongation | 4.5N/mm | |
| Full Thickness Tensile Strength | 20N/-- | |
| Length Range (mm) | 180-3300 | |
| Length Tolerance (mm) | ±2-5 | |
| Width range(mm) | 400-620 | |
| Width Tolerance(mm) | 50mm-+0.5-m/100mm-1.0mm | |
| Thickness range (mm) | 0.8-3.0 | |
| Thickness Tolerance(mm) | +0.1 |
Features: adjustable coefficient of friction, good abrasion resistance, smooth running
Suitable for: weighing industry, food industry, medical industry, packaging industry, electronics industry and other industries.
 |
Model | 001 |
| Material | Polyurethane | |
| Tensile Material | Polyester | |
| Color | White / Transparent / Gray / Blue / Yellow / Red / Black / Green | |
| Surface | Glossy/Matte/Patterned | |
| Antistatic | Possible | |
| Hardness | 70-90 Shore A | |
| Temperature Resistance Range | -20+80* | |
| Minimum Wheel Diameter | 8mm | |
| 1% Constant Elongation | 4.5N/Mm | |
| Full Thickness Tensile Strength | 20N/-- | |
| Length Range (Mm) | 180-3300 | |
| Length Tolerance (Mm) | ±2-5 | |
| Width Range(Mm) | 400-620 | |
| Width Tolerance(Mm) | 50mm-+0.5-M/100mm-1.0mm | |
| Thickness Range (Mm) | 0.5-3.0 | |
| Thickness Tolerance(Mm) | +0.05 |
Product features: a cloth and two rubber full-body anti-static, surface technology can be done glossy, matte, fabric pattern
Suitable for: all electronic semiconductor industry product transportation and anti-static requirements of the process
 |
Model | JSU01 |
| Material | Polyurethane | |
| Tensile Material | Polyester | |
| Color | Black | |
| Surface | Glossy/Matte/Patterned | |
| Antistatic | Possible | |
| Hardness | 50-90 Shore A | |
| Temperature Resistance Range | -20+80* | |
| Minimum Wheel Diameter | 15mm | |
| 1% Constant Elongation | 4.5N/Mm | |
| Full Thickness Tensile Strength | 20N/-- | |
| Length Range (Mm) | 180-3300 | |
| Length Tolerance (Mm) | ±2-5 | |
| Width Range(Mm) | 400-620 | |
| Width Tolerance(Mm) | 50mm-+0.5-M/100mm-1.0mm | |
| Thickness Range (Mm) | 0.8-3.0 | |
| Thickness Tolerance(Mm) | +0.1 |
 |
Model | JSU02 |
| Material | Polyurethane | |
| Tensile Material | Polyester | |
| Color | Black | |
| Surface | Glossy/Matte/Patterned | |
| Antistatic | Possible | |
| Hardness | 70-90 Shore A | |
| Temperature Resistance Range | -20+80* | |
| Minimum Wheel Diameter | 20mm | |
| 1% Constant Elongation | 8N/Mm | |
| Full Thickness Tensile Strength | 62N/-- | |
| Length Range (Mm) | 180-3300 | |
| Length Tolerance (Mm) | ±2-5 | |
| Width Range(Mm) | 400-620 | |
| Width Tolerance(Mm) | 50mm-+0.5-M/100mm-1.0mm | |
| Thickness Range (Mm) | 1.0-3.0 | |
| Thickness Tolerance(Mm) | +0.15 |
Product features: a cloth and two rubber full belt body anti-static, surface technology can be done glossy, matte, cloth pattern
Suitable for: electronic semiconductor, PCB circuit board and other special conveyor process.
|
Model | JU033 |
| Material | Polyurethane | |
| Tensile Material | high strength polyester | |
| Color | Black | |
| Surface | Glossy/Matte | |
| Antistatic | Possible | |
| Hardness | 50-90 Shore A | |
| Temperature Resistance Range | -20+80* | |
| Minimum Wheel Diameter | 8mm | |
| 1% Constant Elongation | 4.8N/Mm | |
| Full Thickness Tensile Strength | 22N/-- | |
| Length Range (Mm) | 180-3300 | |
| Length Tolerance (Mm) | ±2-5 | |
| Width Range(Mm) | 400-620 | |
| Width Tolerance(Mm) | 50mm-+0.5-M/100mm-1.0mm | |
| Thickness Range (Mm) | 0.6-3.0 | |
| Thickness Tolerance(Mm) | +0.05 |
Features: Surface process can be glossy, matte, cloth, frosted, color can be made according to requirements.
Suitable for: food grade, can be used for all kinds of high requirements of transportation and general product transportation.
 |
Model | SU02 |
| Material | Polyurethane | |
| Tensile Material | Polyester | |
| Color | White / Transparent / Gray / Blue / Yellow / Red / Black / Green | |
| Surface | Glossy / Frosted / Matte / Patterned | |
| Antistatic | NO | |
| Hardness | 70-90 Shore A | |
| Temperature Resistance Range | -20+80* | |
| Minimum Wheel Diameter | 20mm | |
| 1% Constant Elongation | 8N/Mm | |
| Full Thickness Tensile Strength | 62N/-- | |
| Length Range (Mm) | 180-3300 | |
| Length Tolerance (Mm) | ±2-5 | |
| Width Range(Mm) | 400-620 | |
| Width Tolerance(Mm) | 50mm-+0.5-M/100mm-1.0mm | |
| Thickness Range (Mm) | 1.0-3.0 | |
| Thickness Tolerance(Mm) | +0.15 |
|
Model | JSU01 |
| Material | Polyurethane | |
| Tensile Material | Polyester | |
| Color | Black | |
| Surface | Glossy/Matte/Patterned | |
| Antistatic | Possible | |
| Hardness | 50-90 Shore A | |
| Temperature Resistance Range | -20+80* | |
| Minimum Wheel Diameter | 15mm | |
| 1% Constant Elongation | 4.5N/Mm | |
| Full Thickness Tensile Strength | 20N/-- | |
| Length Range (Mm) | 180-3300 | |
| Length Tolerance (Mm) | SIZE 2-5 | |
| Width Range(Mm) | 400-620 | |
| Width Tolerance(Mm) | 50mm-+0.5-M/100mm-1.0mm | |
| Thickness Range (Mm) | 0.8-3.0 | |
| Thickness Tolerance(Mm) | +0.1 |
Product features: full belt body with high temperature effect, can be customized anti-static index, matte surface or cloth pattern
Suitable for: conveying electronic products with temperature and general electronic products with anti-static requirements.
 |
Model | SR02 |
| Material | Heat-resistant Polyurethane | |
| Tensile Material | Polyester | |
| Color | Black | |
| Surface | Matte / Patterned | |
| Antistatic | Possible | |
| Hardness | 90 Shore A | |
| Temperature Resistance Range | -20+120* | |
| Minimum Wheel Diameter | 20mm | |
| 1% Constant Elongation | 8N/Mm | |
| Full Thickness Tensile Strength | 62N/-- | |
| Length Range (Mm) | 180-3300 | |
| Length Tolerance (Mm) | ±2-5 | |
| Width Range(Mm) | 400-620 | |
| Width Tolerance(Mm) | 50mm-+0.5-M/100mm-1.0mm | |
| Thickness Range (Mm) | 1.0-3.0 | |
| Thickness Tolerance(Mm) | +0.1 |
Features: The belt body process can be customized according to different applications, with good anti-sticking effect and a certain degree of high-temperature effect
Suitable for: general conveying, conveying of liquid and solid adhesive process, conveying of products with temperature process and other products.
Features: Silicone surface material, back material can be anti-static PU, can be made according to the requirements of the surface pattern, the surface of the anti-adhesion
Suitable for: general conveying, conveying of liquid and solid adhesive process, conveying of products with temperature, conveying of electronics and other products.
 |
Model | JU02G |
| Material | Silicone / Polyurethane | |
| Tensile Material | Polyester | |
| Color | White / Transparent / Gray / Blue / Yellow / Red | |
| Surface | Glossy / Matte / Patterned / Straight Stripe | |
| Antistatic | Possible | |
| Hardness | 40-70 Shore A | |
| Temperature Resistance Range | -60+150* | |
| Minimum Wheel Diameter | 15mm | |
| 1% Constant Elongation | 8N/Mm | |
| Full Thickness Tensile Strength | 62N/-- | |
| Length Range (Mm) | 180-3300 | |
| Length Tolerance (Mm) | ±2-5 | |
| Width Range(Mm) | 400-620 | |
| Width Tolerance(Mm) | 50mm-+0.5-M/100mm-1.0mm | |
| Thickness Range (Mm) | 1.0-4.0 | |
| Thickness Tolerance(Mm) | +0.15 |
